Writing custom Aspire integrations

Writing custom Aspire integrations

No official integration for your favourite service? No problem!

• 5 min read • Spotted a typo?

Just looking for the code and don’t care for the theory? Skip to the code!

Aspire comes with a lot of integrations out of the box (140 at the time of writing!) but sometimes you need one that doesn’t exist, and this week I ended up opening my (first) PR to the Aspire CommunityToolkit which is where 3rd party integrations with Aspire live. My pull request adds integration for Zitadel which is an OpenId Connect compatible identity service with some very interesting free options and self-hosting (I’m still salty about IdentityServer).

While I was waiting for my PR to merge I already got started on writing my second integration for Permify, more on that when we get into the code. Let’s first take a look at how Aspire handles it’s integrations under the hood and then how we can write our own.

Understanding the building blocks

Aspire’s foundation consists of two key types: IResource and IResourceAnnotation. These define your application’s model as a directed acyclic graph (DAG), where IResource instances represent services, infrastructure elements, or supporting components that together compose a distributed system.

Annotations (IResourceAnnotation) allow attaching additional structured information to a resource without modifying its core class. They’re the primary extensibility mechanism in Aspire, enabling:

  • Core system behaviors (e.g., service discovery, connection strings, health probes)
  • Custom extensions and third-party integrations
  • Layering of optional capabilities without inheritance or tight coupling

Case study: MinIO integration

Let’s examine how the CommunityToolkit handles integrations by looking at their MinIO integration (an S3-compatible storage service).

A typical Aspire integration consists of three main components:

1. The Resource type

The resource type represents your service in Aspire’s application model. For MinIO, this means creating a class that:

  • Extends ContainerResource (since MinIO runs as a container)
  • Implements IResourceWithConnectionString to generate connection strings
  • Defines endpoints that other resources can reference
  • Uses ReferenceExpression to create connection string templates that Aspire resolves at runtime

The key insight here is that the resource isn’t just data - it’s a live reference that gets resolved when your application starts.

2. Builder extensions

These are the extension methods you call in your AppHost project, like builder.AddMinio("minio"). They:

  • Create instances of your resource type
  • Configure container settings (image, ports, environment variables)
  • Handle parameters like credentials with sensible defaults
  • Return an IResourceBuilder<T> so you can chain additional configuration

Following Aspire’s builder pattern ensures your integration feels natural alongside official integrations.

3. Client integration

This is what consuming services use to connect to your resource. The client integration:

  • Reads from Aspire’s standard configuration paths
  • Retrieves connection strings by name
  • Configures the actual client SDK (in this case, the MinIO .NET client)
  • Allows additional customization through callbacks

The end result is that in your API project, you just call builder.AddMinioClient("minio") and everything wires up automatically.

What this looks like in practice

With these pieces in place, using the integration is straightforward:

// AppHost
var minio = builder.AddMinio("minio");

builder.AddProject<Projects.MyApi>("api")
    .WithReference(minio);
// API project
builder.AddMinioClient("minio");
// MinIO client is now available via DI

Aspire handles service discovery, connection string management, configuration injection, and container lifecycle - you just declare what you need.

Writing our own integration - Permify

While looking for an authorization service for my current side project (shameless plug: meshum.dev), I came across Permify, which is inspired by Google’s Zanzibar.

Looking at their documentation, running a development Permify server is as simple as:

docker run -p 3476:3476 -p 3478:3478  ghcr.io/permify/permify serve
# Or, if you're using Podman like me
podman run -p 3476:3476 -p 3478:3478  ghcr.io/permify/permify serve

Modeling this in Aspire’s resource model is easy enough, we just throw in an .AddContainer:

var permify = builder.AddContainer("permify", "permify/permify")
	.WithImageTag("latest") // Or pin to a specific version
	.WithImageRegistry("ghcr.io");

Reading on from Permify’s documentation, they tell us that the above will start Permify with the following:

  • Port 3476 is used to serve the REST API.
  • Port 3478 is used to serve the GRPC Service.
  • Authorization data stored in memory.

To be able to access these ports (both ourselves and other services), we need to tell Aspire about them:

permify
	.WithHttpEndpoint(targetPort: 3476, name: "http") // `http` is the default name, so this could be omitted
	.WithHttpEndpoint(targetPort: 3478, name: "grpc");

Permify also has health checks, which means we can tell Aspire how to check if it’s ready (or if it crashed), which in turn will allow us to do things like .WaitFor(permify) since that means “wait until health checks pass”. According to their documentation their health checks run at <http-endpoint>/healthz, so let’s tell Aspire to use them:

permify.WithHttpHealthCheck("/healthz");

Unfortunately, every time we restart Aspire we’ll lose everything as Permify is currently holding everything in memory. Let’s see about adding a Postgres database to our Permify instance, which already supports persistent data volumes so we keep our database between runs.

Permify’s documentation tells us that we can configure a Postgres database by setting the PERMIFY_DATABASE_ENGINE and PERMIFY_DATABASE_URI variables:

var permifyDb = builder.AddPostgres("database")
	.WithDataVolume() // Persists database state between runs
	.AddDatabase("permify-db");

permify
	.WithEnvironment("PERMIFY_DATABASE_ENGINE", "postgres")
	.WithEnvironment("PERMIFY_DATABASE_URI", permifyDb.Resource.UriExpression);

The key here is permifyDb.Resource.UriExpression, which is of type ReferenceExpression - this is how Aspire templates values that get resolved at runtime (in this case a template like postgresql://{user}:{password}@{host}:{port}/{database}).

Let’s put the whole thing together:

var builder = DistributedApplication.CreateBuilder(args);

var database = builder.AddPostgres("database")
    .WithDataVolume();

var permifyDb = database.AddDatabase("permify-db");
var permify = builder.AddContainer("permify", "permify/permify")
	.WithImageTag("latest")
	.WithImageRegistry("ghcr.io")
    .WithHttpEndpoint(targetPort: 3476, name: "http")
    .WithHttpEndpoint(targetPort: 3478, name: "grpc")
    .WithHttpHealthCheck("/healthz")
    .WithEnvironment("PERMIFY_DATABASE_ENGINE", "postgres")
    .WithEnvironment("PERMIFY_DATABASE_URI", permifyDb.Resource.UriExpression)
    .WaitFor(permifyDb);

Permify also has support for OTLP (which is what Aspire uses for its metrics & traces), but I haven’t fully figured out an idiomatic way to have it send those to Aspire (I’m getting close though, currently investigating HostUri).

I hope that this helps you figure out writing your own integrations next time you find yourself needing a service that Aspire doesn’t provide out of the box. As for Permify, I’m hoping to create a PR to the CommunityToolkit so that the above is integrated and you don’t need to write this yourself 😊
